Naish ADX Nvision 2025
The ADX Nvision is the perfect balance between low-end power and top-end speed, with easy handling, it’s the ideal choice for anyone wanting a versatile wing that caters universally to all conditions and riding styles. We’ve created a monster… Optimized shaping and innovative Nvision technology make this wing a force to be reckoned with by pushing the envelope and aligning to consumer demand through critical testing within our passionate and experienced R&D team.
This year the ADX Nvision features a smaller diameter Leading Edge and new ergonomic strut shaping giving the wing more balance and efficiency into wind. Experience superior lightness and a more responsive feel thanks to increased draft stability. Rides are more predictable and jumps reach new heights with the increased air-frame stiffness from the Aluula Leading edge and struts. Feel at ease while scooping and pumping with a longer composite carbon handle, refining the position of hand placement. This allows you to flag easily and optionally ride with a single point harness line, while the center-strut shape is scalloped for ergonomic knuckle space.
The redesigned window shaping and radial panel layout with dual luff panels reinforces strength throughout the wing and provides direct feedback when handling, minimizing stretch and further increasing durability and longevity of tension. Experience peak performance with the ADX Nvision; unmatched innovation and versatility.
Aluula Leading Edge and Struts
Extremely lightweight, unmatched stiffness. Providing improved pump efficiency and increased draft stability in top end performance.
NEW Carbon Boom
Single carbon Boom for refined hand positioning and maximum durability, resulting in improved balance and control with scalloped strut for ergonomic handling.
Improved Low-End Power
Due to draft depth and redefined profile, steady low end “get go power”.
Improved Top-End Speed
Due to increased airframe strength and smaller leading edge diameter, improved hand pressure balance, refined canopy shaping and draft distribution.
Refined Shape
Tuned profile per size provides smoother power delivery increasing the upwind angle and allowing access to power all the time.
Construction
Quad-Tex + Aluula combined for unrivaled strength.
Radial Panel Layout
Radial panel layout with dual luff panels gives reinforced strength and shape, increasing durability and longevity of tension.
Dual Valve System with new PSI Recommendations
Increased rigidity in strut configuration due to dual PSI recommendation.
Wrist Leash Included
Size | Aspect ratio | Handles | Strut length m | Wingspan m |
---|---|---|---|---|
3.5 | 2.794 | Composite boom | 1.66 | 3.142 |
4.0 | 2.719 | Composite boom | 1.78 | 3.285 |
4.5 | 2.746 | Composite boom | 1.32 | 3.49 |
5.0 | 2.763 | Composite boom | 2.02 | 3.68 |
5.5 | 2.757 | Composite boom | 2.07 | 3.84 |
6.0 | 2.653 | Composite boom | 2.2 | 3.939 |
6.5 | 2.535 | Composite boom | 2.33 | 3.995 |
7.0 | 2.443 | Composite boom | 2.42 | 4.082 |
The gear you know and love, reimagined. The Aluula material amplifies the playful and high performance characteristics you have come to love in Naish products.
It’s extremely light weight.
Typical Dacron weighs around 160 gsm, whereas Aluula Gold comes in at a mere 82 gsm. That is half the weight! When thinking about things that fly, it would be an overstatement to say that “weight matters”. Not only does this weight savings make the overall feel of a kite more spry and lively, it also helps performance immensely in marginal wind conditions. A lightweight yet responsive kite really helps make more drive/power in the kite both in light wind and stronger conditions.
It’s insanely rigid.
Not only is the Aluula fabric significantly stronger in warp and weft orientations, its tensile strength is upwards of 5 times stronger than traditional Dacron. This helps significantly with overall frame rigidity, allowing for us to build more intuitively reactive and aerodynamically efficient structures. Lightning fast turn response is the hallmark of Aluula Gold, all thanks to its efficient transfer of energy and loads throughout the kite’s more robust frame.
It lasts.
With its extremely high tear, puncture, and abrasion resistance, the Aluula Gold material is extremely durable. The woven strand “core” material is up to 8x stronger than steel of the same diameter. When combined with the high tensile strength of the outer laminate layers we have a material specifically designed to maximize durability over the complete life span of the kite.
Aluula is hydrophobic.
This may seem like a negligible feature, but its resistance to taking on any additional water keeps the material from gaining un wanted weight from the absorption of water. Not only does this help keep your kite dry and lightweight, but the material also doesn’t promote the growth of organic materials, aka no moldy kites.
It has top level UV resistance.
Again, like its hydrophobic nature, its amazing UV resistance can be easily overlooked. However, nothing destroys kites and wings faster than the harsh UV exposure from long hours in the sun. Most windsports are performed during the daylight hours, therefore the gear is subjected to plenty of harsh hours of UV. This ultimately degrades the strength, responsiveness, and durability of the material resulting in overall performance losses. Thanks to its advanced and durable UV coatings, the Aluula Gold material will extend the life of your kite much longer than a traditional Dacron kite.
Naish ADX Nvision 2024
Introducing the premium version of the ADX, the Wing-Surfer ADX Nvision, it is significantly lighter and dramatically more rigid, resulting in a more direct feel and higher pump efficiency. Built to cater to the needs of riders who demand nothing but the best, the ADX Nvision boasts a cutting-edge Helium Frame construction that utilizes 82 gsm Aluula, making it extremely lightweight and stiff without compromising durability. With a sleek and stylish design that embodies the signature ADX feel, this high-end wing is the epitome of performance and precision. Its dual “luff panel” locks the shape of the wing in place, providing maximum draft stability in a wide wind range. The 50D Nano ripstop canopy, renowned for its low-stretch and tear-resistant features, ensures the ADX Nvision is built to handle even the most intense conditions.
High Aspect Geometry – A wider wingspan gives maximum power efficiency
Hybrid T-Bone Leading Edge Construction – The T- stringer construction stiffens the wing structure and increases efficiency High V Dihedral
Inflated Structure – Increased dihedral provides optimized riding balance
Ergonomic Curved Strut – Optimized for hand position, making it easier to sheet in
Rigid Handle Design – Aluminum drop shape handle design gives maximum efficiency and control
Optimized Window Design – The multi-window design provides visibility where it is needed most
Maximum Pumping Efficiency – The direct feel of the wing translates into optimized pumping efficiency
Optimized Draft Stability – The locked-in draft of the wing gives a wide wind range
Optimized Power Delivery – Provides ultimate low-end power and is highly responsive
Optimized Canopy Tension – Increases power delivery and provides a direct feel
Size | Aspect Ratio | Wingspan (m) | Strut Length (m) | Weight (KG) | Weight (LB) |
3.0 | 2,787 | 2,856 | 1,55 | 1,844 | 4,153 |
3.5 | 2,784 | 3,065 | 1,66 | 2,024 | 4,462 |
4.0 | 2,781 | 3,276 | 1,77 | 2,159 | 4,759 |
4.5 | 2,812 | 3,569 | 1,92 | 2,25 | 4,96 |
5.0 | 2,818 | 3,751 | 2,02 | 2,43 | 5,357 |
5.5 | 2,824 | 3,841 | 2,07 | 2,513 | 5,54 |
6.0 | 2,728 | 3,953 | 2,2 | 2,626 | 5.789 |
7.0 | 2,511 | 4,087 | 2,42 | 2,831 | 6,241 |
